| 粘度指標 | 測量范圍 | From 0 – 1cP to 0 – 10 9 cP over 10 models |
| 測量時間 | 1 second |
| 測量精度 | 1% of reading or +/- 1 digit |
| 測量重復性 | 0.3% of reading or +/- 1 digit |
溫度指標 | 標準 | -50 °C to 150 °C |
| HT高溫性 | -50 °C to 400 °C |
| 高溫定制 | Temperature greater than 150 / 400 °C to order* |
壓力指標 | 標準 | 法蘭標準 |
| 高壓可定制 | To order for extreme pressure * |
過程連接 | 標準 | 法蘭，螺紋，咔咕，ll flanges, threads, clamps, hygienic |
| 接口定制 | Non-standard process connection to order * |
| 電氣連接 | 信號線長度 | As required – not affected by cable length up to 1000m |
| 信號線類型 | Any standard instrument cable |
| 供電 | VP Processor powered |
| 危險區域 | All instruments available for Ex Hazardous Area, explosive atmospheres |
| | Ga Ex ia IIC T1…T6 |
結構 | All welded, crevice-free | |
材質 | 表頭 | SS316 ( EN 1.4401) |
| 安裝接口 | As Required |
| 傳感器 | SS316 ( EN 1.4401) and SS316L ( EN 1.4404) as standard |
| 傳感器可選材質 | Alloy C22 (EN 2.4602) |
| | Alloy C276 (EN 2.4819) |
| | S32750 Duplex Steel (EN 1.4410) |
| 特殊材質 | Non-standard materials to order * |
表面處理 | 標準 | N6 0.8 Ra |
| Finish Options | Fluoropolymer |
| | Electropolished |
| | Electroplated |
| Special Finish | Non-standard finish options and coatings to order * |
防護等級 | Standard | IP67 |
軟件 | ViscoLink data viewing and logging PC software |
| | |
* 定制服務 | Custom variations to instrument specification and dimensions routinely provided by our dedicated Special Operations division |
| | |
| As it is Hydramotion’s policy to continuously develop and improve its products, some specifications may change without notice |
